180-360kw Multi-Standards DC Super Charging station

Overview:

The 180~360kW DC Fast Charger is an all-in-one charging station designed for speed and serviceability. It provides 375A (Max 500A) , 1000V max output ability but no need Liquid cooled cable. For 800V system EV charging for 10min to 300km range.The all-inclusive charger significantly reduces installation and maintenance costs. It features a 15-inch LCD touchscreen display to provide drivers with an intuitive charging process Available 4 cables configurations at most, they are configured with either CCS/CHAdeMO/GBT/NACS connector or DC adapter,DC adapters let every plug become flexible (CCS/GBT/CHAdeMO/NACS) to 100% for Utilization rate.. This DC Fast Charger stands out featuring high-performance, compatibility, and serviceability.

Description:

1.Multi-standards all in one station,supports up to 4dc cables or DC adapter,DC adapters let every plug become flexible (CCS/GBT/CHAdeMO/NACS) to 100% for Utilization rate.

2.375A (Max 500A) , 1000V max output ability but no need Liquid cooled cable.
3.Charge up to 4 vehicles simultaneously.
4.Safe and intuitive to use,Short circuit and over temperature protection.
5.Stationary IP54,IK10.
6.Emergency stop button.
7.OCPP1.6 network integration,We can offer OCPP server back-end management system.
8.4G/Ethernet/Wifi communication,Firmware & Software remote update supported.
9.Payment system PNC, NAYAX, RFID, QR code optional.
10.Split type customized design is comming.
